HK链式地板开槽机的研制与应用

Development and Application of HK Chain Floor Slotting Machine

摘要: 为了实现新型材料PVC、SPC等地板锁扣开槽工艺，而研发设计出一款自动进料地板背部开槽机。该地板背部开槽机可用于厚度为1~10 mm，宽为50~2500 mm，长度为50~2500 mm的地板。通过伺服电机带动切削主轴，完成切削锯片的切削动作，其精度误差可以控制在0.1 mm范围内。同时可以控制伺服电机的参数进行控制锯片的旋转速度，伺服电机安装在燕尾调节机构上可通过调节扳手控制3个自由度实现调节，用于对不同尺寸规格的地板进行开槽。

Abstract: In order to achieve the slotting process of new materials such as PVC and SPC for floor locks, a slotting machine for the back of the feeding floor has been developed and designed. This floor back slotting machine can be used for floors with a thickness of 2~10 mm, a width of 300~2500 mm, and a length of 0~2500 mm. By driving the cutting spindle with a servo motor, the cutting action of the cutting blade is completed, and its accuracy can be controlled within a range of 0.1 mm. At the same time, the parameters of the servo motor can be controlled to control the rotation speed of the saw blade. The servo motor is installed on the dovetail adjustment mechanism and can be adjusted by adjusting the wrench to control 3 degrees of freedom, which is used for slotting floors of different sizes and specifications.
