不同速度等级列车对长大隧道初始压缩波传播特性影响初探
Preliminary Study on the Influence of Trains with Different Speed Classes on the Propagation Characteristics of Initial Compression Waves in Long Tunnels
摘要: 文章基于三维仿真软件，采用某在研列车头型(鼻长15 m)三编组列车及隧道净空面积为100 m2的10 km长大隧道计算模型，对列车速度等级分别为350 km/h、400 km/h和450 km/h高速铁路隧道初始压缩波传播过程进行CFD数值模拟。研究表明，350 km/h和400 km/h速度等级下压缩波在传播过程中发生波前变形且出现波动的局部峰值，压力波动稳定后其幅值由于摩擦效应随传播距离增大而减小，呈现“激化”特征，未出现“衰减”。其次，450 km/h速度等级下压缩波最大压力梯度值呈现先增大后减小的趋势，即该速度等级下压缩波已呈现出先“激化”后“衰减”的特征，其最大“激化”距离出现在7 km左右，即5 km和9 km之间。最后，随着列车速度等级的提高，隧道内同一测点的压力梯度最大值均不同程度地增大；较350 km/h速度等级而言，400 km/h及450 km/h速度等级列车在长大隧道初始压缩波传播过程中压力梯度增大趋势逐渐增大，并在7 km左右增大趋势逐渐减小，这可能与各速度等级对应的最大“激化”距离范围内压力梯度的主导因素由非线性效应逐渐向摩擦效应倾斜有关。研究结果可为初始压缩波的传播及其畸变规律提供一定参考。
Abstract: Based on the 3D simulation software, this paper adopts the calculation model of a 10 km long tunnel with a train head type (nose length 15 m) and a tunnel headroom area of 100 m2. The initial compression wave propagation process of high-speed railway tunnels with train speed classes of 350 km/h, 400 km/h, and 450 km/h was simulated by CFD. The results show that the compression waves at 350 km/h and 400 km/h velocity classes have wave-front deformation during the propagation process. After the pressure fluctuation is stabilized, the amplitude of the compression waves decreases with the increase of the propagation distance due to the friction effect, and the local peak value of the fluctuation appears, showing the feature of “intensification”, and there is no “attenuation”. Secondly, the maximum pressure gradient value of the compression wave at the speed level of 450 km/h presents a trend of first increasing and then decreasing. That is, the compression wave at this speed level has shown the characteristics of first “intensification” and then “attenuation”, and its maximum “intensification” distance is about 7 km, that is, between 5 km and 9 km. Finally, with the increase of train speed grade, the maximum pressure gradient of the same measuring point in the tunnel increases to different degrees. Compared with the speed class of 350 km/h, the pressure gradient of 400 km/h and 450 km/h trains gradually increases during the initial compression wave propagation in the long tunnel, and the increasing trend gradually decreases around 7 km. This may be related to the gradual change from a nonlinear effect to a frictional effect of the dominant factor of pressure gradient in the range of maximum “intensification” distance corresponding to each velocity class. The results can provide some reference for the propagation and distortion of the initial compression wave.
文章引用：张昭, 侯文斌. 不同速度等级列车对长大隧道初始压缩波传播特性影响初探[J]. 力学研究, 2024, 13(4): 167-178. https://doi.org/10.12677/ijm.2024.134017

参考文献

[1] 梅元贵, 等. 高速铁路隧道空气动力学[M]. 北京: 科学出版社, 2009.
[2] 小澤智. トンネル内の圧力波の変形とトンネル出口微気圧波[J]. 日本流体力学会誌「ながれ」, 1995, 14(3): 191-197.
[3] Ehrendorfer, K. and Sockel, H. (1997) The Influence of Measures Near the Portal of Railway Tunnels on the Sonic Boom. BHR Group Conference Series Publication, 863-876.
[4] Ehrendorfer, K., Reiterer, M. and Sockel, H. (2002) Numerical Investigation of the Micro Pressure Wave. In: Schulte-Werning, B., Grégoire, R., Malfatti, A. and Matschke, G., Eds., TRANSAERO—A European Initiative on Transient Aerodynamics for Railway System Optimisation, Springer, 321-341. [Google Scholar] [CrossRef]
[5] Lin, T., Yang, M., Zhang, L., Wang, T. and Zhong, S. (2024) Influence of Bionics Shark Gills Tunnel Portal on the Micro-Pressure Wave at the Tunnel Exit. Tunnelling and Underground Space Technology, 144, Article 105542. [Google Scholar] [CrossRef]
[6] 福田傑, 飯田雅宣, 前田達夫, 等. 高速鉄道のスラブ軌道トンネル内を伝ぱする圧縮波の解析: (第1報, 現地測定と一次元数値解析) [J]. 日本機械学会論文集B編, 1998, 64(621): 1391-1397.
[7] Miyachi, T., Saito, S., Fukuda, T., Sakuma, Y., Ozawa, S., Arai, T., et al. (2015) Propagation Characteristics of Tunnel Compression Waves with Multiple Peaks in the Waveform of the Pressure Gradient: Part 1: Field Measurements and Mathematical Model. Proceedings of the Institution of Mechanical Engineers, Part F: Journal of Rail and Rapid Transit, 230, 1297-1308. [Google Scholar] [CrossRef]
[8] 宮本雅章, 有田貴司, 大森洋志, 等. 超高速鉄道トンネル内に発生する圧力変動履歴の再現と覆工構造の疲労に関する検討[J]. 土木学会論文集A1 (構造∙地震工学), 2020, 76(1): 94-109.
[9] Iyer, R.S., Kim, D.H. and Kim, H.D. (2023) Effect of Ambient Air Temperature on the Compression Wave Propagating along a Railway Tunnel. Journal of Applied Fluid Mechanics, 16, 905-919.
[10] 刘洪涛, 梅元贵, 刘坤. 高速铁路隧道长度对压缩波波前变形的影响研究[J]. 现代隧道技术, 2007, 44(3): 6-10.
[11] 王宏林, 雷波, 毕海权. 压缩波惯性作用对其波形演变的影响[J]. 西南交通大学学报, 2015, 50(1): 118-123.
[12] 刘金通. 高铁隧道内压缩波传播规律及微气压波声学特性初步分析[D]: [硕士学位论文]. 成都: 西南交通大学, 2018.
[13] Doi, T., Ogawa, T., Masubuchi, T. and Kaku, J. (2010) Development of an Experimental Facility for Measuring Pressure Waves Generated by High-Speed Trains. Journal of Wind Engineering and Industrial Aerodynamics, 98, 55-61. [Google Scholar] [CrossRef]
[14] Degen, K.G., Gerbig, C. and Onnich, H. (2007) Acoustic Assessment of Micro-Pressure Waves Radiating from Tunnel Exits of DB High-Speed Lines. Noise and Vibration Mitigation for Rail Transportation Systems, Munich, 4-8 September 2007, 48-55. [Google Scholar] [CrossRef]
[15] Saito, S. (2024) Alleviation of Micro-Pressure Waves Radiated from Tunnel Hoods. Tunnelling and Underground Space Technology, 147, Article 105703. [Google Scholar] [CrossRef]
[16] 猪頭宏平. 長距離管内を伝播する弱い圧力波の波形の違いによる伝播特性への影響[D]: [硕士学位论文]. 福冈: 九州大学, 2018.
