废旧光伏组件回收方法与技术体系综述——回收工艺路线、关键技术与体系化评述
Overview of Recycling Methods and Technological Systems for Waste Photovoltaic Modules—Recycling Process Routes, Key Technologies, and Systemic Evaluation
摘要: 随着全球光伏装机容量的快速增长，退役光伏组件数量在未来十年将迎来爆发式增长，高效、绿色和经济可行的回收利用技术成为保障光伏产业链可持续发展的关键。本综述系统梳理了晶硅与薄膜光伏组件的结构特征及其退役后材料回收技术，重点评述了当前主流的机械拆解、热解脱胶、化学溶胀、湿法冶金、物理化学联用及外场强化等技术路线的研究进展、机理基础、技术优势与瓶颈。最后提出“高效低损伤拆解–绿色化脱胶–精细化金属/硅回收–多路径高值化利用”的技术发展路线，以期为退役光伏组件回收利用的产业布局、技术研发和政策制定提供参考。
Abstract: With the rapid expansion of global photovoltaic (PV) installations, the volume of decommissioned PV modules is expected to surge dramatically over the next decade. Developing recycling technologies with efficient, environmentally benign, and economically viable has therefore become essential for ensuring the sustainable development of the PV industry chain. This review provides a systematic overview of the structural characteristics of crystalline-silicon and thin-film PV modules, along with their resource recovery requirements after end-of-life. It critically examines the research progress, underlying mechanisms, technological advantages, and existing bottlenecks of the major recycling routes, including mechanical dismantling, pyrolysis-based delamination, chemical swelling, hydrometallurgical recovery, physico-chemical combined processes, and externally enhanced methods. Finally, a prospective technology roadmap—“high-efficiency, low-damage dismantling, green delamination, refined recovery of metals and silicon, and multi-path high-value reutilization”—is proposed to guide industrial deployment, technology development, and policy formulation for large-scale PV module recycling.
文章引用：张稼捷, 高超. 废旧光伏组件回收方法与技术体系综述——回收工艺路线、关键技术与体系化评述[J]. 环境保护前沿, 2026, 16(1): 70-81. https://doi.org/10.12677/aep.2026.161009

参考文献

[1] Allouhi, A., Rehman, S., Buker, M.S. and Said, Z. (2023) Recent Technical Approaches for Improving Energy Efficiency and Sustainability of PV and PV-T Systems: A Comprehensive Review. Sustainable Energy Technologies and Assessments, 56, Article ID: 103026. [Google Scholar] [CrossRef]
[2] Zhang, D., Chen, J., Jia, R., Gao, Z., Tao, K., Wang, L., et al. (2022) Texture Engineering of Mono-Crystalline Silicon via Alcohol-Free Alkali Solution for Efficient PERC Solar Cells. Journal of Energy Chemistry, 71, 104-107. [Google Scholar] [CrossRef]
[3] 梁振南, 秦红, 沈辉. 背板材料对太阳电池效率影Ⅱ向的实验研究[J]. 材料研究与应用, 2008, 2(4): 432-436.
[4] 刘景洋. 废晶体硅太阳能电池板资源回收技术研究[R]. 北京: 中国科协海峡两岸青年科学家学术活动月两岸环保高层专家论坛, 2015.
[5] Sah, D., Chitra, and Kumar, S. (2023) Investigation and Recovery of Copper from Waste Silicon Solar Module. Materials Chemistry and Physics, 296, Article ID: 127205. [Google Scholar] [CrossRef]
[6] Shin, J., Park, J. and Park, N. (2017) A Method to Recycle Silicon Wafer from End-Of-Life Photovoltaic Module and Solar Panels by Using Recycled Silicon Wafers. Solar Energy Materials and Solar Cells, 162, 1-6. [Google Scholar] [CrossRef]
[7] Wang, R., Song, E., Zhang, C., Zhuang, X., Ma, E., Bai, J., et al. (2019) Pyrolysis-Based Separation Mechanism for Waste Crystalline Silicon Photovoltaic Modules by a Two-Stage Heating Treatment. RSC Advances, 9, 18115-18123. [Google Scholar] [CrossRef] [PubMed]
[8] Bogust, P. and Smith, Y.R. (2020) Physical Separation and Beneficiation of End-Of-Life Photovoltaic Panel Materials: Utilizing Temperature Swings and Particle Shape. JOM, 72, 2615-2623. [Google Scholar] [CrossRef]
[9] Sultan, B. and Sörvik, E. (1991) Thermal Degradation of EVA and EBA—A Comparison. I. Volatile Decomposition Products. Journal of Applied Polymer Science, 43, 1737-1745. [Google Scholar] [CrossRef]
[10] 徐创, 李宾, 袁晓, 柳翠, 沈春银. 废旧晶体硅光伏组件的回收利用[J]. 环境工程学报, 2019, 13(6): 1417-1424.
[11] 董莉. 废晶体硅太阳能电池板资源化技术研究[D]: [硕士学位论文]. 成都: 西南交通大学, 2014.
[12] Song, B., Zhang, M., Fan, Y., Jiang, L., Kang, J., Gou, T., et al. (2020) Recycling Experimental Investigation on End of Life Photovoltaic Panels by Application of High Voltage Fragmentation. Waste Management, 101, 180-187. [Google Scholar] [CrossRef] [PubMed]
[13] Choi, S. and Kim, E. (2017) Analysis of Pyrolysis Products of Ethylene-Vinyl Acetate Coploymer (EVA) Using Pre-Deacetylation. Journal of Analytical and Applied Pyrolysis, 127, 1-7. [Google Scholar] [CrossRef]
[14] Tao, R., Li, B., Wu, Y., Zhang, W., Yuan, H., Gu, J., et al. (2023) Pyrolysis Mechanism and Recycling Strategy of End-Of-Life Photovoltaic Modules Based on the Experiment and the Density Functional Theory. Polymer Degradation and Stability, 217, Article ID: 110545. [Google Scholar] [CrossRef]
[15] 黄智豪, 巫宇森, 秦保家, 朱洁, 阮菊俊. 退役Cu(InGa)Se2光伏层压件封装材料精准控温热解转化路径及产物分析[J]. 环境工程学报, 2025, 19(2): 373-383.
[16] Theocharis, M., Tsakiridis, P.E., Kousi, P., Hatzikioseyian, A., Zarkadas, I., Remoundaki, E., et al. (2021) Hydrometallurgical Treatment for the Extraction and Separation of Indium and Gallium from End-Of-Life CIGS Photovoltaic Panels. Materials Proceedings, 5, Article 51. [Google Scholar] [CrossRef]
[17] Kang, S., Yoo, S., Lee, J., Boo, B. and Ryu, H. (2012) Experimental Investigations for Recycling of Silicon and Glass from Waste Photovoltaic Modules. Renewable Energy, 47, 152-159. [Google Scholar] [CrossRef]
[18] Tammaro, M., Rimauro, J., Fiandra, V. and Salluzzo, A. (2015) Thermal Treatment of Waste Photovoltaic Module for Recovery and Recycling: Experimental Assessment of the Presence of Metals in the Gas Emissions and in the Ashes. Renewable Energy, 81, 103-112. [Google Scholar] [CrossRef]
[19] Mahmoudi, S., Huda, N., Alavi, Z., Islam, M.T. and Behnia, M. (2019) End-Of-Life Photovoltaic Modules: A Systematic Quantitative Literature Review. Resources, Conservation and Recycling, 146, 1-16. [Google Scholar] [CrossRef]
[20] Li, X., Liu, H., You, J., Diao, H., Zhao, L. and Wang, W. (2022) Back EVA Recycling from C-Si Photovoltaic Module without Damaging Solar Cell via Laser Irradiation Followed by Mechanical Peeling. Waste Management, 137, 312-318. [Google Scholar] [CrossRef] [PubMed]
[21] 董莉, 刘景洋, 周潇云, 郭玉文, 乔琦. 废晶体硅光伏组件中乙烯-醋酸乙烯共聚物热处理及产物分析[J]. 环境污染与防治, 2016, 38(10): 61-66.
[22] Zhang, L. and Xu, Z. (2016) Separating and Recycling Plastic, Glass, and Gallium from Waste Solar Cell Modules by Nitrogen Pyrolysis and Vacuum Decomposition. Environmental Science & Technology, 50, 9242-9250. [Google Scholar] [CrossRef] [PubMed]
[23] 杨迪菲. 废旧晶体硅太阳能电池中金属回收研究[D]: [硕士学位论文]. 上海: 上海第二工业大学, 2019.
[24] Nevala, S., Hamuyuni, J., Junnila, T., Sirviö, T., Eisert, S., Wilson, B.P., et al. (2019) Electro-Hydraulic Fragmentation vs Conventional Crushing of Photovoltaic Panels—Impact on Recycling. Waste Management, 87, 43-50. [Google Scholar] [CrossRef] [PubMed]
[25] Akimoto, Y., Iizuka, A. and Shibata, E. (2018) High-Voltage Pulse Crushing and Physical Separation of Polycrystalline Silicon Photovoltaic Panels. Minerals Engineering, 125, 1-9. [Google Scholar] [CrossRef]
[26] Smith, Y.R., Nagel, J.R. and Rajamani, R.K. (2017) Electrodynamic Eddy Current Separation of End-Of-Life PV Materials. In: Zhang, L., et al., Eds., Energy Technology 2017, Springer, 379-386. [Google Scholar] [CrossRef]
[27] 赵江英. 晶硅太阳能电池片的再生循环技术研究[D]: [硕士学位论文]. 西宁: 青海民族大学, 2019.
[28] Doi, T., Tsuda, I., Unagida, H., Murata, A., Sakuta, K. and Kurokawa, K. (2001) Experimental Study on PV Module Recycling with Organic Solvent Method. Solar Energy Materials and Solar Cells, 67, 397-403. [Google Scholar] [CrossRef]
[29] Maani, T., Celik, I., Heben, M.J., Ellingson, R.J. and Apul, D. (2020) Environmental Impacts of Recycling Crystalline Silicon (C-Si) and Cadmium Telluride (CDTE) Solar Panels. Science of the Total Environment, 735, Article ID: 138827. [Google Scholar] [CrossRef] [PubMed]
[30] Lee, J., Lee, J., Ahn, Y., Kang, G., Song, H., Lee, J., et al. (2017) Photovoltaic Performance of C-Si Wafer Reclaimed from End-Of-Life Solar Cell Using Various Mixing Ratios of HF and HNO3. Solar Energy Materials and Solar Cells, 160, 301-306. [Google Scholar] [CrossRef]
[31] 刘强, 冯加保, 黄振华, 等. 晶硅太阳能电池环保回收再生利用的研究[J]. 科技经济导刊, 2016(2): 120-121.
[32] Pagnanelli, F., Moscardini, E., Granata, G., Abo Atia, T., Altimari, P., Havlik, T., et al. (2017) Physical and Chemical Treatment of End of Life Panels: An Integrated Automatic Approach Viable for Different Photovoltaic Technologies. Waste Management, 59, 422-431. [Google Scholar] [CrossRef] [PubMed]
[33] Dias, P., Javimczik, S., Benevit, M., Veit, H. and Bernardes, A.M. (2016) Recycling WEEE: Extraction and Concentration of Silver from Waste Crystalline Silicon Photovoltaic Modules. Waste Management, 57, 220-225. [Google Scholar] [CrossRef] [PubMed]
[34] Kim, Y. and Lee, J. (2012) Dissolution of Ethylene Vinyl Acetate in Crystalline Silicon PV Modules Using Ultrasonic Irradiation and Organic Solvent. Solar Energy Materials and Solar Cells, 98, 317-322. [Google Scholar] [CrossRef]
[35] Schwarz, M.P., Koh, P.T.L., Verrelli, D.I. and Feng, Y. (2016) Sequential Multi-Scale Modelling of Mineral Processing Operations, with Application to Flotation Cells. Minerals Engineering, 90, 2-16. [Google Scholar] [CrossRef]
[36] Liu, J., Bai, X., Hao, J., Wang, H., Zhang, T., Tang, X., et al. (2021) Efficient Liberation of Electrode Materials in Spent Lithium-Ion Batteries Using a Cryogenic Ball Mill. Journal of Environmental Chemical Engineering, 9, Article ID: 106017. [Google Scholar] [CrossRef]
[37] Maisel, F., Chancerel, P., Dimitrova, G., Emmerich, J., Nissen, N.F. and Schneider-Ramelow, M. (2020) Preparing WEEE Plastics for Recycling—How Optimal Particle Sizes in Pre-Processing Can Improve the Separation Efficiency of High Quality Plastics. Resources, Conservation and Recycling, 154, Article ID: 104619. [Google Scholar] [CrossRef]
[38] Zhao, P., Guo, J., Yan, G., Zhu, G., Zhu, X., Zhang, Z., et al. (2020) A Novel and Efficient Method for Resources Recycling in Waste Photovoltaic Panels: High Voltage Pulse Crushing. Journal of Cleaner Production, 257, Article ID: 120442. [Google Scholar] [CrossRef]
[39] Sim, Y., Tay, Y.B., Pham, H.K. and Mathews, N. (2023) A Facile Crush-And-Sieve Treatment for Recycling End-of-Life Photovoltaics. Waste Management, 156, 97-106. [Google Scholar] [CrossRef] [PubMed]
[40] Granata, G., Pagnanelli, F., Moscardini, E., Havlik, T. and Toro, L. (2014) Recycling of Photovoltaic Panels by Physical Operations. Solar Energy Materials and Solar Cells, 123, 239-248. [Google Scholar] [CrossRef]
[41] Azeumo, M.F., Germana, C., Ippolito, N.M., Franco, M., Luigi, P. and Settimio, S. (2019) Photovoltaic Module Recycling, a Physical and a Chemical Recovery Process. Solar Energy Materials and Solar Cells, 193, 314-319. [Google Scholar] [CrossRef]
[42] Fiandra, V., Sannino, L. and Andreozzi, C. (2023) Photovoltaic Waste as Source of Valuable Materials: A New Recovery Mechanical Approach. Journal of Cleaner Production, 385, Article ID: 135702. [Google Scholar] [CrossRef]
[43] 魏晓旭, 王珊, 高德东, 吴智朋. 低温条件下废旧晶硅光伏组件破碎实验研究[J]. 青海大学学报, 2024, 42(1): 17-23.
[44] 王红雪, 付元鹏, 樊玉萍, 董宪姝. 低温焙烧改性-机械破碎分离回收废弃光伏电池[J]. 有色金属(冶炼部分), 2023(9): 51-57, 88.
[45] 张雪峰, 燕阳, 王东, 王志, 伍继君. 液氮改性-机械破碎法分离回收废旧光伏电池板[J]. 矿冶, 2021, 30(3): 19-24.
[46] dos Santos Martins Padoan, F.C., Schiavi, P.G., Belardi, G., Altimari, P., Rubino, A. and Pagnanelli, F. (2021) Material Flux through an Innovative Recycling Process Treating Different Types of End-Of-Life Photovoltaic Panels: Demonstration at Pilot Scale. Energies, 14, Article 5534. [Google Scholar] [CrossRef]
[47] Li, M., Widijatmoko, S.D., Wang, Z. and Hall, P. (2023) A Methodology to Liberate Critical Metals in Waste Solar Panel. Applied Energy, 337, Article ID: 120900. [Google Scholar] [CrossRef]
[48] 徐雪冬, 刘斌, 吴雪, 王晶, 刘美莲. NaOH溶液预处理结合超声制备微纤化纤维素的研究[J]. 纤维素科学与技术, 2019, 27(1): 57-64.
[49] 罗斌, 刘全军, 余力, 江旭, 纪慧超. RSM在超声波强化氧化铜矿浸出试验中的应用[J]. 有色金属工程, 2019, 9(2): 59-63.
[50] 宋红玮, 许忠斌, 郑素霞. 微波辅助回收废聚酯制备粉末涂料用聚酯树脂[J]. 化工学报, 2008(8): 2141-2148.
[51] 赵晓非, 刘立新, 李杰, 毕立娜, 张东. 聚对苯二甲酸乙二醇酯微波水解反应方式分析及机理研究[J]. 材料导报, 2007(S2): 10-12.
[52] Ghosh, S. and Yadav, R. (2021) Future of Photovoltaic Technologies: A Comprehensive Review. Sustainable Energy Technologies and Assessments, 47, Article ID: 101410. [Google Scholar] [CrossRef]
[53] Ewa, R., Piotr, O., Adam, C., et al. (2010) Chemical, Thermal and Laser Processes in Recycling of Photovoltaic Silicon Solar Cells and Modules. Ecological Chemistry and Engineering S, 17, 385-391.
